Cone Angle OG Ground Center Holes: 60 Deg..

Max Diameter of Ground Center Holes: 2"

Max. Diameter of Workpiece: 5"

Max. Length of Workpiece: 43"

Headstock Axis-Column Face: 6"

Grinding Spindle Speeds (3): 45,000 RPM, 22,500 RPM, 13,000 RPM

Quill Speeds (2): 800 RPM and 400 RPM

Feed of Grinding Cone: .030" - .200"

Grinding Spindle Motor: ½ HP, 230/460V, 3PH, 60CY

Diameter of Grinding Spindles: ¾”, 1 ¼”, 1 ¾”

Equipped With

Vise Jaws

Diamond Dresser
